Speaker Type

2-Way/Active Coaxial Stage Monitor

Acoustical data

Frequency Response [-6dB]

58-17.800 Hz

Max SPL

128 dB

HF

1 ”Exit 1.4” v.c

Directivity (HxV)

90” x 70”

LF

15”, 2,5 v.c

Amplifier

Amp Technology

Digipro G3

Amp Class

Class-D

RMS Power

600 W

Peak Power

1200 W

Power Supply

SMPS with PSU Auto-range

Power Connection

PowerCon In/Link

Cooling

Convection

Processor

Controller

DSP 56 bit

AD/DA converter

24bit/48kHz

System Presets

8 presets

Limiter

RMS, Peak, Thermal

Processing (filters)

FIR Linear Phase

Controls

Rotary 8 positions, MIC/LINE switch

Input

Mains Connections

PowerCON in/link

Signal Input

1 x Combi IN (XLR/Jack)

Signal output

1 x XLR link OUT

USB connector

Mini USB B-Type (service only)

Mechnaics

Housing

Plywood with black PVC Cover

Grille

Metal, black painted

Handles

2 x chassis integrated

Pole Mount

D36 mm

Dimensions (weith x Height x Depth)

640 x 460 x 370 mm

Weight

22.3 kg
