The Classic Series features Furman revolutionary Series Multi-Stage Protection (SMP), Linear Filtering Technoloty (LiFT), and Extreme Voltage Shutdown (EVS). Together, these technologies comprise what is, without question, one of the world’s most advanced and comprehensive transient voltage surge suppresor.
Technical Specifications
Response Time: 1 nanosecond
Maximum Surge Current: 6,500 amps
Construction: Steel chassis, 3mm brushed and black anodized aluminum front panel; glass epoxy printed circuit boards
Line Voltage: 240 Volts
AC Protection Technology: Extreme Voltage Shutdown, Series Multi-Stage Protection, Non-sacrificial protection with zero ground contamination
Current Rating: 16 Amps
Operating Voltage: 180 to 274 VAC
Over Voltage Shutdown: 275 VAC typically
Spike Protection Modes: Line to neutral, zero ground leakage
Spike Clamping Voltage: 376 VAC peak @ 3,000 Amps, 266 VAC RMS
Noise Attenuation: 10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz Linear attenuation curve from 0.05 – 100 Ohms line impedance
Dimensions: 44.45mm H x 482.6mm W x 266.7mm D
Weight: 5.5 kg
Power Consumption: 25 VA
Safety Agency Listing: CE
