dBTechnologies DVA K5 3-way active line array

14.495,00 kr. inkl. moms

❌ Varen på fjernlager, leveringstid 8-14 dage

❌ Varen på fjernlager, leveringstid 8-14 dage

Varenr.: DVA K5Kategorier: DVA K5, DVA K5Tags: DVABrand: dBTechnologies

Pdf: MANUAL DVA K5

The DVA K5 line array module comprises two 1,4” drivers, a 6” neodymium midrange and a 8” neodymium woofer.
Furthermore, an advanced DSP user interface allows an extremely precise system tuning: a double rotary encoder provides a separate tuning for LF correction (coupling) and MF/HF correction (high-angle midrange loss and air absorption compensation due to throw distance).
The module’s electronics and components are housed in a sturdy polypropylene box, reinforced with an internal anti-vibration metal structure which drastically reduces any resonance, allowing the cabinet to achieve an excellent acoustic response.
The unique design, the selected components and a state of the art amplifying technology come together to deliver an exceptional weight-performance ratio: each system weights 31,31 lbs (14,2 Kg). Moreover, DVA K5 comes with a freshly designed frontal grille and an integrated raincover.



FEATURES

  • 3-WAY ACTIVE LINE ARRAY MODULE
  • 500 W RMS DIGIPRO G3 AMP TECHNOLOGY
  • 129 dB MAX SPL
  • FREQUENCY RESPONSE [+/- 3 dB]: 80 – 19.000 Hz
  • HF: 2x 1″, 1.4” v.c.
  • MF: 1x 6.5″, 2″ v.c. – NEODYMIUM
  • LF: 1x 8″, 2.5” v.c. – NEODYMIUM



Technical Data
Speaker Type: 3-Way Active Line Array Module
Acoustical data
Frequency Response [+/- 3dB]: 70 – 19,000 Hz
Max SPL: One Unit: 129 dB
HF: 2×1 “
Voice Coil HF: 1.4 “
MF: 1x 6.5 “
Type MF: Neodymium
Voice Coil MF: 2 “
LF: 1×8 “
Voice Coil LF: 2.5 “
Type LF: Neodymium
Directivity (HxV): 100×15° Single unit
Amplifier
Amp Technology: Digipro® G3
Amp Class: Class D
RMS Power: 500 W
Peak Power: 1000 W
Cooling: Convection
Power Supply: 500 W SMPS with Auto Range PSU
Processor
Controller: DSP 56 Bit
AD/DA Converter: 24 bit/48 KHz
Limiter: Dual Active Multiband RMS, Peak, Thermal
Crossover Frequency MF-HF: 1800 Hz
Slope MF-HF: 24 dB/Octave
Crossover Frequencies LF-MF: 340 Hz
Slope LF-MF: 24 dB/Octave
Input
Signal Input: 1x XLR Balanced
Signal Output: 1x XLR Balanced
Power Socket: 1x PowerCON In – 1x PowerCON Out
Controls: 1 x Input Sensitivity Rotary Switch – 1 x DSP Rotary Encoder (LF Correction) – 1 x DSP Rotary Encoder (MF-HF Correction)
Mechanics
Housing: Polypropylene PP metal reinforced
Rigging Points: Integrated rigging hardware
Width: 580 mm
Height: 240 mm
Depth:327 mm
Weight: 14.2 kg
