From the dBTecnologies experience in the world of sound reinforcement, the first high-performance point source for high-profile installations is born.
Combining excellent acoustic performance with the versatility guaranteed by dedicated accessories for flyable or pole configurations, IS210T is a solution designed for sound reinforcement in medium and large environments such as arenas, performing arts center, houses of worship, multifunctional venues, and clubs.
The symmetrical configuration with two 10” woofers makes the top performing both in indoor and outdoor acoustic contexts; the IP55 certification ensures high resistance to different weather conditions and increase the system durability. IS210T is available in white and black, with the possibility of customizing the color finish of the white version by yourself.
Features
PASSIVE 2-WAY FULLRANGE SPEAKER
MAX SPL 133 dB
FREQUENCY RESPONSE [-6dB]: 60 Hz – 17,800 Hz
HF: 1x 1.4″ (exit), 2.4″ v.c.
LF: 2x 10″, 2.5″ v.c.
IP55 CERTIFIED
ROTATABLE HORN
PASSIVE 2-WAY FULLRANGE SPEAKER
MAX SPL 133 dB
FREQUENCY RESPONSE [-6dB]: 60 Hz – 17,800 Hz
HF: 1x 1.4″ (exit), 2.4″ v.c.
LF: 2x 10″, 2.5″ v.c.
IP55 CERTIFIED
ROTATABLE HORN
WEIGHT: 28.7 Kg (63 lbs)
Technical Data
Speaker Type: 2-way Passive Fullrange Speaker
Acoustical data
RMS Power: 400W (LF: 300W | HF: 100W)
Peak Power: 1600W (LF: 1200W | HF: 400W)
Usable bandwidth [-10 dB]: 56 Hz – 20,000 Hz
Frequency Response [-6 dB]: 60 Hz – 17,800 Hz
Impedance: 8 Ohm
Max SPL: 133 dB
HF: 1x 1.4″ (exit), 2.4″ v.c.
LF: 2x 10″, 2.5″ v.c.
Dispersion: 90×40° [rotatable horn]
X-Over Frequency: 840 Hz (internal X-Over)
Input
Connections: Screw terminal block (LF+ | LF- | HF+ | HF-)
Mechanics
Housing: Multiplex plywood – Polyurea painting
Rigging points: flyable with bracket
IP rating: IP 55
Width: 300 mm
Height: 780 mm
Depth: 430 mm
Weight: 28.7 Kg
