Remarkably powerful (1800 W peak) for its compact size, this complete PA system is designed for a quick and smooth set up, equally responding to musicians and djs needs.
ES 1002 includes one cover for the sub and one cover for the top module.
Features
- BI-AMPED 1800 W ACTIVE PA SYSTEM
- IMPROVED POWER/SIZE RATIO
- EXTRA-PRECISE COVERAGE DISPERSION (HORIZONTAL AND VERTICAL)
- NEW PHASE-PLUG DESIGN FOR PERFECT INTELLIGIBILITY
- ENHANCED USABILITY FOR CONTROL PANEL
- 8 EQ PRESETS
Technical Data
Speaker Type: BI-Amped Mono Column System
Acoustical data
Frequency Response [-10dB]: 43 – 20.000 Hz
Max SPL: 130.7 dB
MF – HF: 8x 4″
Type MF – HF: Neodymium
LF: 2x 12″
Directivity (HxV): 97×40°
Amplifier
Amp Technology: Digipro® G3
Amp Class: Class-D
Power Amp Peak: 1800 W
Processor
Controller: DSP 24 Bit/48 kHz
System Presets: Flat – Bass boost – Bass reduction – Playback – Speech – Long throw – HPF 80 Hz – HPF 120 Hz
Limiter: Dual Active, Peak, RMS, Thermal
Controls: DSP rotary encoder, volume controles, MIC/LINE Switch
Crossover Frequency LF-HF: 160 Hz
Input
Mains Connections: VDE
Signal Input: 1x Combo (XLR/Jack) balanced/unbalanced input – Mic/Line, 1x RCA stereo input
Signal Out: 1x XLR balanced output with aux volume + 1x speakon to top
Mechanics
Housing (Subwoofer): Black Painted Plywood
Housing (Tops): Multiplex Plywood
Handles: 3 (1 on top + 1 each side on sub)
Pole Mount: 36 mm (M20 threaded hole)
Width (Top): 110 mm (4.33 in)
Height (Top): 905 mm (35.63 in)
Depth (Top): 160 mm (6.3 in)
Width (Subwoofer): 360 mm (14.17 in)
Height (Subwoofer): 680 mm (26.77 in)
Depth (Subwoofer): 545 mm (21.46 in)
Weight (Top): 5.8 Kg – 12.79 lbs
Weight (Subwoofer): 29.3 Kg – 64.59 lbs
