LVX active loudspeakers series is the answer to all those fixed installations and live music requirements where sound reinforcement systems must be lightweight, stylish, portable, powerful. As a result of the experience in touring gear designing, the new LVX series offers smart solutions with a special attention to the needs of fixed and portable installations.
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 65 – 20.000 Hz
Frequency Response [-6dB]: 80 – 19.000 Hz
Max SPL: 121 dB
HF: 1″
Directivity: 90 x 70°
Horn:Rotatable CD Horn
LF: 8″
Amplifier
Amp Technology: Digipro® G2
Amp Class: Class-D
Peak Power: 800W
PRG Power: 400 W
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Crossover Frequency LF-HF: 2050 Hz
Slope LF-HF: 24 dB/Octave
Mechanics
Housing: MDF
Angles Up: Monitor use 40°
Handles: 1x top side, recessed
Rigging points: 10 x M8
Pole Mount: D36 mm
Width: 260 mm (10.24 in)
Height: 420 mm (16.54 in)
Depth: 260 mm (10.24 in)
Weight: 10.1 kg (22.27 lbs)
