Technical Data

Speaker Type

2 Way Active Loudspeaker

Acoustical data

Freq. Response (-6dB)

80 – 20.000 Hz

Usable Bandwidth (-10dB)

75 – 21.000 Hz

Max SPL

126 dB

HF

1 x 1” – 1,4” v.c.

LF

2 x 5” – 1” v.c.

VIO X205-60 Directivity

60° x 60 g°

VIO X205-100 Directivity

100° x 100°

Amplifier

Amplifier

400 W RMS Class D Digipro G3

Cooling

Convection

Power Supply

Auto-range SMPs

Processor

Controller

DSP 28/56 bit

Converter AD/DA

24 bit/48 bit

Limiter

Peak, RMS, Thermal

Processing

FIR Linear Phase Filters

Input

Signal Input

1x XLR balanced, 1xRJ45 Link (RDNet), 1x USB (data Service)

Signal Output

1x XLR balanced, 1x FJ45 Link (RDNet)

Power Socket

1x PowerCon TRUE1 In

X PowerCon TRUE1 Out

Controls

1x Rotary Encoder (8 EQ presets)

1x Input Attenuation Rotary Switch

1x On LED

1x Status -LED

1x Signal Led

1x Limiter LED

Mechanics

Housing

Wooden cabinet, Polyurea painting

Handles

1x (top)

Wedge Angle

Monitor use 5°

Riggin points

2x M10 Threaded Nuts (top and bottom)

Dimensions (WxHxD)

150 x 485 x 240 mm

Weight

7,8 kg
