dBTechnologies presents two new point-source models within the acclaimed OPERA series, raising the bar and bringing a real revolution at a perfect time, 50 years from the foundation of the company. Introducing the all-new standard in professional portable sound, made in Italy: OPERA REEVO.
FEATURES
- Quasi 3-way configuration
- Coaxial transducers
- 2x Neodymium woofer
- 1050 W RMS / 2100 W Peak
- 132.5 dB Max SPL
- Acoustic phase plug
- FIR Filters
- 3x Flying point
- Low noise reflex port
- Made in Italy
Technical Data
Speaker Type: Quasi 3-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 54 – 19.400 Hz
Frequency Response [- 6dB]: 60 – 19.100 Hz
Max SPL: 132.5 dB
HF: 1″ Exit CD, 1.75″ v.c.
Type HF: Compression driver
Horizontal Directivity: 100°
Vertical Directivity: 90°
Horn: Asymmetrical Horn
LF: 2x 10″ Neo, 2.5″ v.c.
Amplifier
Amp Technology: Digipro G2 with SMPS
Amp Class: Class D
RMS Power: 1050 W (525W + 525W)
Peak Power: 2100 W (1050W + 1050W)
Processor
Controller: DSP 28/56 bit
AD/DA Converter: 24 bit/48 KHz
CrossOver Frequency: 1260 Hz
Limiter: Peak, RMS, Thermal
Advanced DSP Functions: Linear Phase FIR Filters
Input
Signal Input: 1x Combo (XLR/Jack 6.3 mm) Line
Signal Output: 1x XLR Male (True link)
Controls: Gain (rotary) Preset (Flat, Playback, Wedge)
Mechanics
Housing: Polyproylene
Grille: Full grille
Handles: 1 on left Side, 1 on Top
Rigging Points: 2x M10 on Top + 1x M10 on Back
Pole Mount: D36 mm
Width: 300 mm (11.81 in)
Height: 604 mm (23.78 in)
Depth: 324 mm (12.76 in)
Weight: 17.2 kg (37 lbs)
