LVX active loudspeakers series is the answer to all those fixed installations and live music requirements where sound reinforcement systems must be lightweight, stylish, portable, powerful. As a result of the experience in touring gear designing, the new LVX series offers smart solutions with a special attention to the needs of fixed and portable installations.
Technical Data
Speaker Type: 2-Way Active Speaker
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 55 – 20.000 Hz
Frequency Response [-6dB]: 62 – 19.000 Hz
Max SPL: 127 dB
HF: 1″
Directivity: 90 x 40°
Horn: Rotatable CD Horn
LF: 12″
LF: 12″
Amplifier
Amp Technology: Digipro® G2
Amp Class: Class-D
Peak Power: 1600 W
PRG Power: 800 W
PRG Power: 800 W
Processor
Controller:DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Crossover Frequency LF-HF: 1800 Hz
Slope LF-HF: 24 dB/Octave
Slope LF-HF: 24 dB/Octave
Mechanics
Housing: Multiplex
Angles Up: Monitor use 45°
Handles: 3 (1x top side, 1x side)
Rigging points: 12 x M10
Pole Mount: D36 mm
Width: 360 mm (14.17 in)
Height: 610 mm (24 in)
Depth: 360 mm (14.17 in)
Weight: 17 kg (37.5 lbs)
