FEATURES
- DESIGNED FOR OPTIMIZED ACOUSTIC AND MECHANICAL COMPATIBILITY WITH VIO L210
- NEW ACOUSTIC DESIGN FEATURING ALL-IN-ONE PHASE PLUG AND HF HORN FRONT PANEL
- LOW-LATENCY PROCESSING THANKS TO POWERFUL DSP WITH LINEAR-PHASE FIR FILTERS
- FULLY COMPLIANCE WITH AURORA NET REMOTE CONTROL SOFTWARE
- DSP PRESETS FOR MAXIMUM ACOUSTIC CUSTOMIZATION
- BUILT-IN FLYING HARDWARE ALLOWING FAST & EASY SET UP AND FLYING OPERATIONS
|
Technical Data |
|
|
Speaker Type |
2-way Active Line Array Module |
|
Acoustical data |
|
|
Frequency Response (-6dB) |
75 Hz – 20 KHz |
|
Frequency Response (+/-30dB) |
85 Hz – 18.1 KHz |
|
Max SPL |
133,5 dB |
|
HF |
1 x 1.4” |
|
Voice Coil HF |
3” |
|
Type HF |
Neodymium |
|
LF |
2 x 8” |
|
Voice Coil LF |
2” |
|
Type LF |
Neodymium |
|
Horizontal Directivity |
100° |
|
Vertical Directivity |
Depends on array size and configuration |
|
Amplifier |
|
|
Amp Technology |
Digipro G3 |
|
Amp Class |
Class D |
|
Power RMS |
900 W |
|
Peak Power |
1800 W |
|
Cooling |
Convection |
|
Power Supply |
900 W AMPS with Auto-range PSU |
|
Processor |
|
|
Controller |
DSP 28/56 bit |
|
AD/DA Converter |
24 bit/48KHz |
|
Limiter |
Dual Active Peak, RMS, Thermal |
|
Processing (filters) |
FIR Linear Phase Filters |
|
Crossover Frequency LF-HF |
1000 Hz |
|
Input |
|
|
Signal Input |
1 x XLR fem, Bal. |
|
Signal Output |
1 x XLR male, Bal. |
|
Network |
RDNet remote control RJ45 connector IN/OUT |
|
Mains Connections |
1 x PowerCON TRUE1 IN 1 x PowerCON TRUE1 OUT |
|
Controls |
1 x Speakers Coupling (7 presets) 1 x HF Compensation (8 presets) 1 x Input Attenuation Rotary Switch |
|
Mechanics |
|
|
Housing |
Multiplex plywood Polyurea painted |
|
Handles |
1x Side, 2 on back |
|
Raincover |
Included |
|
Rigging Points |
Integrated 3-point flying hardware |
|
Dimensions (WxHxD) |
600x260x390 mm |
|
Weight |
18,1 kg |
